SPECIFICATIONS

• Item
  - Parameter
• Model

  - COT121PCA

• Series

  - 12.1" Water-proof, Dust-proof and Compact

• Monitor Dimensions

  - Width: 287.0mm Height: 273.5mm Depth:42.8(without bezel)/45.0mm(with bezel)

• Weight（N.W/G.W）

  - 3.5Kg / 4.3Kg (Approx.)

• LCD Type

  - 12.1 inch WSXGA Color TFT-LCD

• Video Input

  - VGA and DVI, HDMI optional

• Active Area(mm)

  - 246.0mm(H)x184.5mm(V)

• Resolution

  - 1024x768 @ 60 Hz

• Dot Pitch(mm)

  - 0.24825x0.24825

• Direct Input Voltage

  - +12.0VDC(Typ)

• Viewing angle (v/h)

  - 60?70?degree

• Contrast

  - 600:1

• Luminance(cd/m2)

  - 250

• Response Time (Rising/Falling)

  - 6s/6s

• Support Color

  - 16.7M colors

• Backlight MTBF(hr)

  - 50000

• Touchscreen accuracy

  - 4096*4096

• Touchscreen light transmission

  - 92%

• Working Temperature

  - Operating Temp.0 -50 C

• -

  - Storage Temp. -20-60 C

• Working Humidity

  - Operating RH:20%-80%

• -

  - Storage RH: 10%-90%

• OSD controls

  - Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset

• OSD on Screen Display language)

  - Simplified Chinese, traditional Chinese, English,

• -

  - French, Italian, Spanish, German, Japanese, Korean

• Mount Interface

  - 1)VESA 75mm and 100mm

• -

  - 2)Mount bracket, horizontal or vertical

• Regular Warranty

  - 3 years for touchscreen; 1 year for LCD

• Agency Approval

  - FCC,CE

• Power input

  - 100-240 VAC, 50-60 Hz
