ZKTEK provides all kinds of custom OEM/ODM ATM machine,interactive kiosk,information kiosk, touchscreen kiosk, touchscreen monitor, touchscreen computer, box ipc,digital sginages, pos and metal keyboard products

D43 roof mount digital signage

Model: D43

D43 roof mount digital signage
D43 roof mount digital signage

D43 roof mount digital signage
Priced from: $650

MAIN FEATURES

  • Full HD

    Full HD or FHD is the high definition 1920x1080 progressive.

  • Multitouch

    Multitouch is the touchscreen with the multi touch points recognition simultaneously.

  • HD is high definition.
  • Multitouch is the touchscreen with the multi touch points simultaneously.

  • D43 roof mount digital signage




  • Configurations

    • 42" touchscreen Android digital signage with RK3066 MP4 board Specifications

      Name Item Parameter
      Host PC CPU Onboard RK3066 quad core CPU
      Video core Integrated HD graphics graphic card support 1920*1080 full HD
      RAM Onboard 1*DDR3 RAM 1GB(Max 2GB)
      Storage Onboard 4G flash(upgradeable)
      Interfaces LVDS, USB, LAN
      Touchscreen Type 42 inch infrared multitouch touchscreen
      Durability Scratch-free,More than 35,000,000 touches in one location without failure
      - antirust, anti-acid, anti-dust
      Thickness 6mm
      Resolution 4096x1096
      Light Transmission 90%-92%
      Surface Hardness Mohs
      Touch force <100g
      Response Time 16ms
      Interface USB
      LCD Type 42 inch TFT LCD
      Brightness 450cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Package Material Plywood crate
      Wrapper Film
      Foam (only corners)

    • 46" touchscreen digital signage with J1900 CPU Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 46 inch TFT LCD
      Brightness 400cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.297
      Interface LVDS
      Touchscreen Type 42 inch infrared multitouch touchscreen
      Durability Scratch-free,More than 35,000,000 touches in one location without failure
      - antirust, anti-acid, anti-dust
      Thickness 4mm
      Resolution 4096x1096
      Light Transmission 90%-92%
      Surface Hardness Mohs
      Touch force <100g
      Response Time 16ms
      Interface USB
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Audio AUDIO Stereo amplified speakers: dual channel 5W8Ohm

    • 32 inch digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 32 inch TFT LCD
      Brightness 350cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Audio AUDIO Stereo amplified speakers: dual channel 5W8Ohm

    • 42 inch digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 42 inch TFT LCD
      Brightness 450cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)

    • 46 inch digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 46 inch TFT LCD
      Brightness 400cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.297
      Interface LVDS
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Audio AUDIO Stereo amplified speakers: dual channel 5W8Ohm

    • 52 inch digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 52 inch TFT LCD
      Brightness 300cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Audio AUDIO Stereo amplified speakers: dual channel 5W8Ohm

    • 22 inch digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 22 inch TFT LCD
      Brightness 300cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(HD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
      Audio AUDIO Stereo amplified speakers: dual channel 5W8Ohm

    • 24 inch digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 24 inch TFT LCD
      Brightness 300cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)

    • 26 inch full HD digital signage with J1900 Specifications

      Name Item Parameter
      Host PC CPU Onboard Intel bay trail dual-core J1800/J1900, dual core 2.41GHz~2.58GHz, 1333MHz FSB
      Video core Integrated Intel HD graphics graphic card support 1920*1080 full HD
      RAM 1*SO-DIMM(1.35V low voltage),DDR3 RAM 4GB(Max 8GB)
      Storage 2* Serial ATA II, support 3Gb/s
      - 500G HDD(legacy 2.5″ hard driver)
      LCD Type 26 inch TFT LCD
      Brightness 300cd/m2
      Contrast 2000:1
      Max(native). resolution 1920x1080(FHD)
      Response Time 6ms
      Dot pitch 0.197
      Interface LVDS,VGA or DVI
      Enclosure Type of material Durable all-steel enlcosure
      Type of paint Powder coated front, powder coated steel back covers
      Style Ergonomically sleek and smart design
      - Easy to install and operate with internal drawers
      Ventilation Internal fans for ventilation
      Protection Security mechanic locks
      Environment Moistureproof,Antirust,Anti-acid,Static free
      Wheels (optional)
